4″ Submersible Pumpset – Oil Filled

Catalogue Download

Salient Features

  • Oil cooled, rewindable motor
  • High operating efficiency & Low power consumption
  • Withstand wide voltage fluctuation
  • Maintenance free operation due to ball bearing
  • Noiseless & vibration free operation
  • Easily dismountable & Repairable

Application

  • Water Supply System
  • Flow / Drip / Sprinkler irrigation
  • Fire Fighting
  • Civil & Industrial
  • Bungalows & Apartments

Product Range

CharacteristicsSingle PhaseThree Phase
Suitable for Borewell size4″ & Above4″ & Above
Power Range (KW/HP)0.37/0.5 – 2.2/3.00.75/1.0 – 2.2/3.0
Speed2850 rpm2850 rpm
Version 230 V, 50Hz380/415 V, 50Hz
Stage 4 to 445 to 45
Head Meter3 to 1903 to 196
Feet10 to 62310 to 643
Discharge M³/hr22.5 to 0.75 22.5 to 0.75
LPM 375 to 13 375 to 13
Duty S1S1
MountingNEMA / Non NEMA NEMA / Non NEMA
Outlet Size1¼”, 1½”, 2″1¼”, 1½”, 2″
Available MOCStandardStandard

Material Of Construction

Motor ComponentMaterial
Stator Body / ShellAISI 202
Upper HousingCast Iron
Lower HousingCast Iron
Base CoverCast Iron
Rotor ShaftAISI 410 / 431
Shaft Seal Carbon Ceramic
Ball BearingCarbon Steel
DiaphragmNBR
Lead Cable PVC
Sand GuardNBR
HardwareStainless Steel

Material Of Construction

Pump ComponentStandard
Pump Jacket/ Shell / Body AISI 202
Pump CasingNoryl
ImpellerNoryl
NRV HousingCast Iron
Suction CasingCast Iron
Pump ShaftAISI 410
Pump SleeveAISI 410
HardwareStainless Steel
